PreSonus Quantum 2626 Thunderbolt 3 Audio Interface
$86.00
The PreSonus Quantum 2626 is a 26×26 Thunderbolt 3 audio interface. The Quantum 2626 takes advantage of the jaw-dropping speed of Thunderbolt 3 to achieve a barely measurable round-trip latency of less than 1 millisecond. Superb high-definition digital conversion and eight ultratransparent analog XMAX mic preamps ensure your audio always sounds its best. Streamline your recording process and make better music, faster with the Quantum 2626. Timeless Audio
Superior Sound
Expansive Audio
Included Studio One Software
Timeless Audio
The Quantum 2626’s completely redesigned Thunderbolt driver delivers ultralow-latency performance. It features cutting-edge 24-bit, 192kHz converters with 115dB of dynamic range and superior low-jitter clocking. Coupled with ultratransparent, pure analog PreSonus XMAX preamps, the 2626 serves up superb audio quality.
Superior Sound
The Quantum 2626 audio interface operates at up to 192kHz for ultrahigh-definition mixing and recording. High-quality converters provide 115dB of dynamic range. This helps capture complex harmonics naturally with no audible distortion. The Quantum 2626 also features acclaimed XMAX Class A analog microphone preamps. These deliver high headroom, deep lows, smooth highs and a rich, overall sound.
Expansive Audio
Impressive speed combined with stunning sound quality means that the Quantum Thunderbolt audio interface is an ideal solution for any size studio. Need more mic preamps? Connect the PreSonus DigiMax DP88 to your Quantum interface’s ADAT/dual S/MUX ports. Once synced, the DigiMax DP88 preamps can be remotely controlled via Studio One or UC Surface. Want to insert your favorite gear? The Quantum 2626 features two direct preamp outputs with dedicated returns, so you can insert your favorite analog compressor and your favorite plug-ins with ease.
Included Studio One Software
Quantum 2626 ships with Studio One Artist music production software included. Studio One enables you to compose, record and produce without getting distracted by the tools. Need a new loop or sample for your latest production? PreSonus Studio One lets you audition and purchase new content right from your production environment.
Flexible Connectivity
- Simultaneous I/O up to 26 inputs / 26 outputs (at 44.1 or 48kHz)
- 8 pristine XMAX preamps
- 2 Instrument Inputs
- 8 balanced line inputs
- Dual headphone outputs with independent level control
- Balanced stereo main outputs with independent level control
- 8 DC Coupled balanced line outputs
- 2 preamp direct outputs with returns to insert outboard gear
- Main Output Level Control
- Balanced Stereo Main Output (TRS)
- Eight Balanced Line Outputs (TRS (outs 1 & 2 share a DAC with the main output))
- Two Preamp Outputs (channels 1 & 2)
- Two Line Returns (channels 1 & 2)
- ADAT Optical/Dual SMUX inputs/outputs: 16×16 channels at 44.1 or 48kHz; 8×8 channels at 88.2 or 96 kHz
- Stereo S/PDIF coaxial input and output
Digital
- Thunderbolt 3 high-speed bus
- 24-bit resolution and up to 192 kHz sampling rate
- BNC word clock input and output with low-jitter clocking
- MIDI I/O
Physical
- Road-rugged construction with all-metal chassis and metal knobs
- 1U rackmountable
- 12 VDC external power supply (included)
Audio Quality
- Max bit depth: 24-bit
- Max sampling rate: 192kHz
- Frequency response: 20Hz–20kHz
Digital Audio
- Connection Type: Thunderbolt 3 (Thunderbolt 1 and 2 compatible)
- ADC Dynamic Range: 115dB (A-wtd)
- DAC Dynamic Range: 115dB (A-wtd)
- Bit Depth: 24 bits
- Internally Supported Sample Rates: 44.1, 48, 88.2, 96, 176.4, 192kHz
Microphone Preamp
- Type: XLR Female (via Combo), Balanced
- Maximum Input Level: +10dBu (Balanced, min. gain)
- Gain Control Range: 60dB
- Dynamic Range: > 110dB (A-wtd, min. gain)
- EIN: < -131 dBu (max gain, 40 ohm, 22kHz BW, A-wtd)
- Input Impedance: 1.6 kohm
- Phantom Power: +48V, > 8 mA per input
Instrument Inputs
- Type: ¼” TS Female (via Combo), Unbalanced
- Maximum Input Level: +15dBu (Unbalanced, min. gain)
- Gain Control Range: 60dB
- Dynamic Range: > 106dB (A-wtd, min. gain)
- Total Harmonic Distortion: < 0.005% (1kHz, min. gain)
- Input Impedance: > 1 mohm
Line Inputs
- Type: 1/4” TRS Female (via Combo), Balanced
- Maximum Input Level: + 18 dBu (Balanced, min. gain)
- Dynamic Range: > 118dB (A-wtd, min. gain)
- Input Impedance: 10 kohm
Main and Line Outputs
- Type: 1/4” TRS Female, impedance balanced, DC Coupled (Line Outputs only)
- Maximum Output Level: +18 dBu (Balanced)
- Frequency Response: 20Hz to 20kHz (±0.05dB, unity gain, 48kHz)
- Dynamic Range: > 118dB (A-wtd)
- Output Impedance: 51 ohm
Headphone Outputs
- Type: 1/4” TRS Female, Stereo, Unbalanced, x2
- Maximum Output Level: 175 mW/channel (56Ω load)
- Dynamic Range: > 110 dB (A-wtd)
- Headphone Impedance (working range): 16 ohm to 300 ohm
Clock
- Jitter: < 70 ps RMS (20Hz–20kHz)
- Jitter Attenuation: > 60dB (1 ns in => 1 ps out)
Power
- 12 VDC, 5A, external power supply
Dimensions
- Height: 1.75″ (44.45 mm)
- Depth: 7″ (177.8 mm)
- Width: 19″ (482.6 mm)
- Weight: 6 lb. (2.72 kg)
System Requirements
Mac
- Mac OS X 10.11.6 64-bit or later
- Intel Core i5 or better
- 4GB RAM (8 GB or more recommended)
Windows
- Windows 10 64-bit or later
- Intel Core i5 or better
- 4GB RAM (8 GB or more recommended)
Mac and Windows Systems
- Thunderbolt 1.0, 2.0, or 3.0 port (NOTE: Your computer’s motherboard must support Thunderbolt. Thunderbolt 1 and 2 require an adapter, not included.)
- Internet connection (required for Studio One Activation and Content download)
- Internal or external 7200 RPM storage drive highly recommended
- 30GB hard disk space
- Monitor with 1366×768 resolution
