Pure linear cardioid
The principal appeal of the 4011A is its directional quality and attention to detail: everything sounds like the original. The first-order cardioid pickup pattern provides superb separation between sound sources when used as a spot mic on literally any style of live music, from rock Ëœn’ roll to opera. The 4011A is equally suitable for close-up work on acoustic guitar, grand piano, overheads, percussion, wind instruments and vocals as it is for spot-miking symphonies. It can handle incredibly high sound levels and even includes a 20 dB pad switch in the center of the XLR connector to attenuate the output of the microphone.
Hard case and clip included.
Perfectly natural
A flat on-axis frequency response and excellent phase response deliver a totally faithful reproduction of the original sound. The off-axis response is similarly smooth so that any leakage is an accurate reflection of the original, though attenuated according to the true first-order cardioid pickup pattern. The sensation of “being there” will always be more intense with the DPA 4011A than with any other cardioid. Chosen for its qualities as an all-around performer, the 4011A is a great, clean-sounding colorless mic. The variety of applications is as wide as the imagination of the user.
- Frequency response: 20Hz to 20kHz
- Max SPL: 159 dB
Pattern and type
- Capsule: Condenser
- Pattern: Cardioid
- Type: Mounted
- Applications: Studio, stage, theatrical
- Phantom power required: Yes
Size and weight
- Length: 6.7 x “
- Weight: 5.6 oz.
Included accessories
- Case: Hard case
- Clip: Hard rubber
- Power supply: No
- Directional characteristics: Cardioid
- Principle of operation: Pressure gradient
- Cartridge type: Pre-polarized condenser
- Frequency range: 20 Hz to 20 kHz
- Frequency range, ±2 dB: 40 Hz to 20 kHz
- Sensitivity, nominal ±2 dB at 1 kHz: 10 mV/Pa; -40 dB re. 1 V/Pa
- Equivalent noise level, A-weighted, re. 20 Pa: Typ. 18 dB(A) re. 20 Pa (max. 20 dB)
- Equivalent noise level, ITU-R BS.468-4: Typ. 25 dB (correct with the attenuator in 0 dB or -20 dB setting)
- S/N ratio (A-weighted), re. 1 kHz at 1 Pa (94 dB SPL): Typ. 76 dB(A)
- Total Harmonic Distortion (THD): < 1 % up to 139 dB SPL peak
- Minimum load impedance: 2 kohm
- Dynamic range: Typ. 121 dB
- Max. SPL, peak before clipping: 159 dB
- Switchable attenuator: 0 dB / -20 dB
- Output impedance: < 200 ohm
- Cable drive capability: 100 m (328 ft)
- Output balance principle: Impedance balancing with Active Drive
- Common Mode Rejection Ratio (CMRR): > 60 dB
- Power supply (for full specifications): 48 V Phantom power (± 4 V)
- Current consumption: 2.8 mA
- Connector: XLR-3M. Pin 1: shield, Pin 2: signal + phase, Pin 3: – phase
- Color: Matte black
- Weight: 158 g (5.6 oz)
- Microphone diameter: 19 mm (0.75 in)
- Capsule diameter: 19 mm (0.75 in)
- Length: 170 mm (6.7 in)
- Output voltage, RMS: > 5 V
- Polarity: +V at Pin 2 for positive sound pressure
- Temperature range: -40 C to 45 C (14 F to 113 F)
- Relative Humidity (RH): Up to 90 %
- Matching tolerance: ± 1 dB
- Phase deviation for kit: < 10
